Operating the System 17
AS7200 User Manual - OPEX Corporation
IdAssist indicator The blue IdAssist indicator LED will light up when running
a job that includes IdAssist. Also, when the operator triggers IdAssist the LED
will go out briefly, indicating to the operator that IdAssist has been activated.
Figure 1: Main controls and components
Touchscreen monitor
Conveyor
Sort bins
Audit trail
printers
Stacker bypass
bin
PC/UPS
Trash bin
Override feed
AS7200i with Model 72
Rapid Extraction Desk
Main power switch
(see inset)
Main power switch
control butto
