Optek AF16 - Standard Window; Gaskets; Screw Sets

Maintenance
- 41 -
optek-Manual--1004-2001-02--AF16-US-2011-01-04
www.optek.com
9.8.2 Standard window
*** others on request
9.8.3 Gaskets
9.8.4 Screw sets
Tab. 21 Spare parts — standard window
Sensor type / name Name / type Old part number New part number
standard window***
(see corresponding arma-
ture manual)
Pyrex® type A 0410-0050-01
type B 0410-0051-01
type C 0410-0052-01
type K 0410-0053-01
Sapphire type A 0410-0050-03
type B 0410-0051-03
type C 0410-0052-03
type K 0410-0053-03
type AM 0410-0056-03
type BM 0410-0057-03
type CM 0410-0058-03
Tab. 22 Spare parts - gaskets (not wetted)
(4 of each)
Viton
®
Old part number
Viton
®
New part number
10.10 x 1.60 0208-4004-02 1203-0004-0008-02
18.77 x 1.78 0208-4007-02 1203-0004-0013-02
21.95 x 1.78 0208-4001-02 1203-0004-0015-02
25.12 x 1.78 0208-4002-02 1203-0004-0016-02
31.47 x 1.78 0208-4003-02 1203-0004-0018-02
Tab. 23 Spare parts - screw sets (10 of each)
(10 of each) New part number
M3 x 6 (DIN 7985) 1206-0010-0023-03
M3 x 12 (DIN 7985)
incl. washer M3 (DIN 7980)
1206-0010-0077-01
