9.8.5 Validation retrofit sets
9.8.6 Small part sets
9.8.7 Installation material
9.8.8 Reference filter for validation
Tab. 27 Accessories - validation filter for VA option
Tab. 28 Accessories - validation filter for VB option
Selective color validation filters on request.
When ordering a reference filter, the serial number (SN) of the sensor has to be
indicated.
Tab. 24 Spare parts - validation retrofit sets
(1 of each) New part number
validation retrofit set AF16-VA 1414-3131-4003-00
validation retrofit set AF16-VB 1414-3131-8003-00
Tab. 25 Spare parts — small part sets
New part number
set purge connection M5 1201-3131-0001-00
Tab. 26 Spare parts — installation material
New part number
set Klüberpaste UH1 96-402 4 x 12 g 1201-3131-0002-00
Absorption Old part number New part number
0.45 CU 3000-3011-00 1442-0015-0003-11
0.9 CU 3000-3012-00 1442-0015-0003-21
1.8 CU (AF16-N only) 3000-3013-00 1442-0015-0003-31
Absorption Old part number New part number
0.45 CU 3000-3014-00 1442-0015-0003-13
0.9 CU 3000-3015-00 1442-0015-0003-23
1.8 CU (AF16-N only) 3000-3016-00 1442-0015-0003-33
