7
SPECIFICATIONS
7-1
SPECIFICATIONS
Model HX-40 HX-40AM HX-40DAM
Detection method Passive infrared Passive infrared & Microwave
PIR Coverage 12.0 m (40') 85° wide / 94 zones
PIR distance limit 4.0 m, 5.5 m, 9.0 m (13'1", 18'1", 29'6")
Detectable speed 0.3 m/s – 1.5 m/s (1'/s – 4'11"/s)
Sensitivity 2.0°C (3.6°F) at 0.6 m/s
Power input 9.5 – 18 V DC
Current draw
35 mA (max.)
at 12 V DC
40 mA (max.)
at 12 V DC
50 mA (max.)
at 12 V DC
Alarm period 2.0 ±1 sec.
Warm-up period Approx. 60 sec. (LED blinks)
Alarm output Form C 28 V DC 0.2 A (max.)
Tamper output N.C. 28 V DC, 0.1 A (max.) N.C. open when cover removed.
Trouble output – N.C. 28 V DC, 0.1 A (max.)
Aux input N.C. 28 V DC, 0.1 A (max.)
LED indicator
Red: Warm-up,
Alarm
Red: Warm-up,
Alarm,
Trouble
Red:
Warm-up, Alarm, Trouble
Green:
Warm-up, PIR detect, Trouble
Yellow:
Warm-up, MW detect
RF interference No alarm 10 V/m
Operating temperature -20 – +60°C (-4 – +140°F)
Environment humidity 95% max.
Weatherproof IP55
Mounting Wall
Mounting height 2.5 – 3.0 m (8'2" – 9'10")
Bracket adjust angle Vertical: ±20° Horizontal: ±95°
Weight 600 g (21.2 oz.)
700 g (24.7 oz.)
Accessories
Bracket, Hood, Area masking seal, Screw (3 × 10 mm) × 2, Screw (4 × 20 mm) × 4
*Specifications and designs are subject to change without prior notice.
