Optex HX-40 - Knockouts

1-3 KNOCKOUTS
For wall fastening/bracket fastening
(installation pitch 83.5 mm (3.29"))
For main unit fastening
Adjustment screw
Bracket
Main unit
(Off-the-shelf) magnet switch
installation position
For bracket
Up-Down lock screw
Wiring Hole
For wall
fastening
For switch
box fastening
Do not touch
Up-Down
lock screw
Wiring
knockout
Wiring sponge pad
Wiring Hole
- 4 -
