The correct sequence to retrieve the data from the OPN2002/3 using the mini USB cable
would then be connecting your OPN2002/3 to the USB port, clicking on the NetO32
configuration file and then remove the OPN2002/3 from your PC when desired.
Don't forget it regularly needs be charged as well.
10 Loading software on the OPN2002 and OPN2003
The following chapter will describe how to load new software onto the OPN2002/3.
Important note: When installing a new Operating System on the OPN2002/3 any
barcode data left on the device might be lost!
10.1 Software codes
All OPN2002 and OPN2003 terminals run an OS (operating system) and an application.
Both the OS and the application can be loaded by a small PC application called Appload,
which can be download from our web site.
The OPN200x terminals use an Operating System version that contains an unique 3 letter
code. Before you try to load a new Operating System on an OPN200x terminal you have to
know which Operating System file (i.e. RBFVxxxx.S2) must be loaded on your terminal.
In the table below you can find the software codes for the OPN200x terminals.
* It is often possible to load OPN2002 applications on the OPN2003 and vice versa,
because the hardware is mostly the same (besides Bluetooth capabilities and cradle
contacts that are only present on the OPN2002).
10.2 Loading software using the mini-USB cable
To be able to load software on the OPN200x using the mini USB cable first make sure
you’ve selected the USB-VCP interface (see chapter 3.1), because USB-MSD is not yet
supported to install software. Also make sure you have the USB-VCP driver installed on
your PC (see chapter 7.1).
10.3 Loading software on the OPN2002
To load a new OS or application onto the OPN2002, you'll need a mini-USB cable (which is
supplied with the OPN2002) or the CRD2000 cradle.
