Optoma ES522 - Page 3

Delta Elec. Inc. ES522 & EX532
Company Confidential Optoma___________________ Delta________________
3
2009/06/30
5-9.OPTIONS / Advanced…………………………….………………………………………….86
6. Calibration…………………………….………………………………………….………………..87
7. Color Border Adjustment………………………………………………………………………...93
8. Projection Lamp…………………………………………………………………………………..94
9. Cleaning…………………………………………………………………………………………...97
10.SERVICE NOTE............................................................................................................... 98
10-1.Service Note Description........................................................................................... 98
10-2.Power & READY LED Blink Code Message...............................................................99
10-3.Factory Preset Display Modes..................................................................................100
11. RS-232 Command……………………………………………………………………………..102
12. EDID………………………………………………………………………………………….....106
13. Spare Part List ...............................................................................................................122
Update History
No. Description Date
1 Primarily 05/20/2009
Update the photos on the cover of service manual (p1)
Lamp spec update to ‘E20.8’ (P6,7)
Add EX532 VGA2 port from VGA2/SCART/YPbPr (p7)
Add VGA Out (p7)
Change Keypad diagram (p12)
2
FW upgrade program suitable is for DDP2000/2230/2430/2431 (p61,73)
06/30/2009
