20 Optomed Aurora
Select the ‘ Image browser’ item by pressing Optoroller to preview captured images.
To view the latest captured images in current patient study, select ‘ IMG ’. If you want
to preview images from other studies, select first the study/patient whose images
you wish to preview. Then select the desired image from the selected study by
using the Optoroller. When the image is shown, the image can be zoomed by
pressing the Optoroller. It is also possible to delete complete studies or
single images.
When imaging with Optomed Aurora Retinal Module, there is a possibility to select
the ‘ Four image sequence ’ item by pressing Optoroller. By selecting four image
sequence, a new patient study is created and the camera will guide to take both
macula and disc centered images from patient’s right and le eyes. Aer each
capture, the image can be zoomed, retaken or you can choose to continue to the
next sequence.
TARGET LEDS FOR AURORA RETINAL MODULE
Optomed Aurora Retinal Module has nine internal fixation targets for the patient to
fixate on during imaging. The middle fixation target is on by default and it provides a
macula centred image. To change the fixation target, select the target LEDs item, then
turn Optoroller le or right to choose the suitable LED and press Optoroller to set the
fixation target.
FOCUS WINDOWS FOR AURORA ANTERIOR MODULE
Optomed Aurora Anterior Module has four focus windows for the user to focus
the image on dierent areas during autofocus imaging. The right focus window is
selected by default and the image is focused to the right side. To change the
focus window, select the focus window item, then turn Optoroller le or right to
choose a suitable area and press Optoroller to set the focus window area.
SETTINGS
To change camera- or optics-specific settings, select the ‘ Settings’ item by pressing
Optoroller. Camera- and optics-specific settings are described in the following
chapters.
