Table below includes explanations of the ES settings tab for anterior eye imaging:
Setting
Values (default bolded)
Purpose
Capture mode
Still / Video
Use left and right arrow keys to choose between still
capture and video capture.
Half press capture
On/Off
Enable capture by pressing shutter button half way.
Focus windows
Visible/Hidden
Use left and right arrow keys to choose between having
focus window visible or hidden.
Mark side
On/Off
Mark side of the eye to the image data.
Zoom cropping
On/Off
When turned on camera will save the zoomed area only.
When turned off camera will save the whole image area
even when zoom is used.
Instant Review
On/Off
Instant review can be ON/OFF according to user need, as
available in ES Optics menu. Instant review image can be
changed from left and right arrow keys.
Capture mode
Both still images and video can be taken with the Smartscope M5 camera. When taking video the shutter
button must be held down while taking the video. The video recording will stop once the shutter button
is released.
Half-press capture
It is possible to take images and video by pressing shutter button halfway down.
Focus Window
Focus Window helps user position the image. Focus Window can be moved on the screen by using Left
soft key and then using the arrow keys when aiming.
Marking side
It is possible to mark which eye was imaged. Marking side is enabled from the menu. When On side is
marked to the file name and to the image. For video files, side is always marked only to the file name.
When marking side is enabled, camera verifies side after each captured image.
- Identifiers used for normal eye images are OS for left and OD for right.
- Identifiers used for red-free images are SG for left and DG for right.
- Identifiers used for save IR images are SI for left and DI for right.
- Identifiers used for low-red images are SC for left and DC for right.
Zoom cropping
With zoom cropping on the camera will save the zoomed area instead of the whole image area. By default
zoom cropping is turned off and camera will save the whole image area instead of the area that is visible
on the camera screen when user has zoomed in.
Instant review
Instant review can be ON/OFF according to user need, as available in ES Optics menu. When the reviewing
zoom level is 1x, user can change the image to be reviewed with left and right arrow keys. Images are in
showing order Normal, Low-red, Red-free, IR.
NOTE: Camera stores selected menu settings when it is powered off.
