optris CSmicro E2015-12-A
8
For a usage of the CSmicro LT for online maintenance applications (in electrical cabinets e.g.) the following
recommend settings are already included in the factory default setting (but not active):
OUT At 3-state output the following settings are default:
Pre-alarm difference: 2 °C
No alarm level: 8 V
Pre-alarm level: 5 V
Alarm level: 0 V
Service voltage: 10 V
IN/ OUT: At Alarm output (open collector) the following settings are default:
Mode: normally closed
Temp code output: activated (for values above alarm level)
Range settings: 0 °C = 0 %/ 100 °C = 100 %
Vcc adjust: If activated the following settings are default:
Output voltage range: 0-10 V
Difference mode: activated
Alarm level Alarm value (IN/ OUT pin) Vcc
1 40 °C 11 V
2 45 °C 12 V
3 50 °C 13 V
4 55 °C 14 V
5 60 °C 15 V
6 65 °C 16 V
7 70 °C 17 V
8 75 °C 18 V
9 80 °C 19 V
10 85 °C 20 V
