optris LT User Manual

optris CSmicro – E2015-12-A
31
Mechanical Installation
The CSmicro is equipped with a metric M12x1 thread and can be installed either directly via the sensor
thread or with the help of the hex nut (standard) to the mounting bracket available. The CSmicro 2WhsLT will
be delivered with the massive housing and can be installed via the M18x1-thread.
Sensing head [LT/ 3M/ 2WLT/ 2W2M]
1)
Sensing head [2WhsLT]
1)
On the LTxxCF and 3MxCF1 models the total length of the sensing head is 32 mm instead of 28 mm.
The sensors CSmicro are sensitive optical systems. Please use only the thread for mechanical installation. Avoid
mechanical violence on the head – this may destroy the system (expiry of warranty).
