optris CSmicro – E2015-12-A
26
Transmission values if the CF lens
is used (average values):
LT 0,78
2M 0,87
3M 0,92
CF Lens and Protective Window
The optional CF lens allows the measurement of very small objects.
The minimum spot size depends on the used sensing head. The
distance is always measured from the front edge of the CF lens
holder or laminar air purge collar. The installation on the sensing
head will be done by turning the CF lens until end stop. To combine
it with the 2WhsLT model please use the version with external
thread M12x1.
Versions Overview:
ACCTCF CF lens for installation on sensing head [LT/ 2WLT]
ACCTCFHT CF lens for installation on sensing head [2W2M]
ACCTCFE CF lens with external thread for installation in massive housing [LT/ 2WLT]
ACCTCFHTE CF lens with external thread for installation in massive housing [2W2M]
For protection of the sensing head optics a protective window is available. The mechanical dimensions are
equal to the CF lens. It is available in the following versions:
ACCTPW Protective window for installation on sensing head [LT/ 2WLT]
ACCTPWHT Protective window for installation on sensing head [2W2M]
ACCTPWE Protective window with external thread for installation
in massive housing [LT/ 2WLT]
ACCTPWHTE Protective window with external thread for installation
in massive housing [2W2M]
Transmission values if the
protective window is used (average
values):
LT 0,83
2M/ 3M 0,93
