optris CSmicro – E2015-12-A
10
Electrical Specifications
Used pin Function LT / 3M 2W _
OUT IN/ OUT
x Analog 0-5 V
1)
or 0-10 V
2)
/ scalable 4-20 mA/ scalable (current loop
between Power and GND pin)
x Alarm output voltage adjustable; N/O or N/C output current adjustable; N/O
or N/C (current loop between
Power and GND pin)
x Alarm 3-state alarm output (three voltage level -
for no alarm, pre-alarm, alarm)
x Alarm programmable open collector output programmable open collector
[0-30 V DC/ 50 mA]
4)
output [0-30 V DC/ 500 mA]
x Temp. Code Temp. Code Output (open collector) Temp. Code Output (open
[0-30 V DC/ 50 mA]
4)
collector) [0-30 V DC/ 500 mA]
x Input programmable functions: programmable functions:
-external emissivity adjustment -triggered signal output and
-ambient temperature compensation peak hold function
5)
-triggered signal output and peak hold -Reset of hold function
7)
function
5)
-Reset of hold function
6)
x x Serial digital
3)
uni- (burst mode) or bidirectional uni- (burst mode) or
bidirectional
Output impedances min. 10 kΩ load impedance max. 1000 Ω loop impedance
Current draw 9 mA 4-20 mA
Power supply 5...30 VDC 5...30 VDC
