optris LT User Manual

optris CSmicro – E2015-12-A
4
Cautions
Avoid abrupt changes of the ambient temperature.
In case of problems or questions which may arise when you use the sensor, please contact our service
department.
Model Overview
The sensors of the CSmicro series are available in the following versions:
Series Models Measurement range spectral Output Optics Specialty
response
LT LT15 -40 to 1030 °C 8-14 µm 0-5/ 10 V 15:1
LT02 -40 to 1030 °C 8-14 µm 0-5/ 10 V 2:1
3M 3ML 50...350 °C 2,3 µm 0-5/ 10 V 22:1
3MH 100 to 600 °C 2,3 µm 0-5/ 10 V 33:1
2WLT 2W LT15 -40 to 1030 °C 8-14 µm 4-20 mA 15:1
2W LT15H -40 to 1030 °C 8-14 µm 4-20 mA 15:1 T
amb
max. 180 °C
2W LT22H -40 to 1030 °C 8-14 µm 4-20 mA 22:1 T
amb
max. 180 °C
2W hsLT -20 to 150 °C 8-14 µm 4-20 mA 15:1 0,025 K resolution
2W2M 2W 2ML 250 to 800 °C 1,6 µm 4-20 mA 40:1
2W 2MH 385 to 1600 °C 1,6 µm 4-20 mA 75:1
The sensors CSmicro are sensitive optical systems. Please use only the thread for mechanical installation.
Avoid mechanical violence on the head – this may destroy the system (expiry of warranty).
