optris CSmicro – E2015-12-A
13
Measurement Specifications
LT15/ LT02 3ML 3MH e
Temperature range IR -40...1030 °C 50...350 °C
4)
100...600 °C
4)
(scalable via software)
Ambient temperature (sensing head) -20...120 °C -20...85 °C -20...85 °C
Spectral range 8...14 µm 2,3 µm 2,3 µm
Optical resolution 15:1/ 2:1 22:1 33:1
CF-lens (optional) 0,8 mm@ 10 mm/ - -
2,5 mm@ 23 mm
CF optics (built-in) - 5,0 mm@ 110 mm 3,4 mm@ 110 mm
CF1 optics (built-in) - 1,5 mm@ 30mm 1,0 mm@ 30 mm
Accuracy
1)
±1,0 °C or ±1,0 %
2)
------- ±(0,3 % of reading + 2 °C) -------
Repeatability
1)
±0,5 °C or ±0,5 %
2)
------- ±(0,1 % of reading + 1 °C) -------
Temperature coefficient
3)
±0,05 K/ K or ±0,05 %/ K (whichever is greater)
Temperature resolution 0,1 K 0,1 K 0,1 K
Response time 30 ms (90 % signal) 25 ms (90 % signal) 25 ms (90 % signal)
Warm-up time 10 min - -
Emissivity/ Gain 0,100...1,100 (adjustable via software)
Transmissivity 0,100...1,000 (adjustable via software)
Interface (optional) USB programming interface
Signal processing Average, Peak hold, Valley hold (adjustable via software)
1)
at ambient temperature 235 °C, whichever is greater; Epsilon = 1; Response time 1 s
2)
at object temperatures > 23 °C
3)
for ambient temperatures <18 °C and >28 °C
4)
TObject > THead+25 °C
