optris CSmicro – E2015-12-A
14
2WLT15 2WLT15H 2WLT22H e
Temperature range IR -40...1030 °C -40...1030 °C -40...1030 °C
(scalable via software)
Ambient temperature (sensing head) -20...120 °C -20...120 °C -20...180 °C
Spectral range 8...14 µm 8...14 µm 8...14 µm
Optical resolution 15:1 15:1 22:1
CF-lens (optional) 0,8 mm@ 10 mm/ 0,8 mm@ 10 mm 0,6 mm@ 10 mm
Accuracy
1)
±1,0 °C or ±1,0 %
2)
±1,0 °C or ±1,0 %
2)
±1,0 °C or ±1,0 %
2)
Repeatability
1)
±0,5 °C or ±0,5 %
2)
±0,5 °C or ±0,5 %
2)
±0,5 °C or ±0,5 %
2)
Temperature coefficient
3)
±0,05 K/ K or ±0,05 %/ K (whichever is greater)
Temperature resolution 0,1 K 0,1 K 0,1 K
Response time 30 ms (90 % signal) 150 ms (90 % signal) 150 ms (90% signal)
Warm-up time 10 min 10 min 10 min
Emissivity/ Gain 0,100...1,100 (adjustable via software)
Transmissivity 0,100...1,000 (adjustable via software)
Interface (optional) USB programming interface
Signal processing Average, Peak hold, Valley hold (adjustable via software)
1)
at ambient temperature 235 °C, whichever is greater; Epsilon = 1; Response time 1 s
2)
at object temperatures > 23 °C
3)
for ambient temperatures <18 °C and >28 °C
