optris LT User Manual

optris CSmicro – E2015-12-A
11
Status LED green LED with programmable functions:
 alarm indication (threshold independent from alarm outputs)
 automatic aiming support
 self diagnostics
 temperature code indication
Vcc adjust mode 10 adjustable emissivity and alarm values by variation of supply voltage/
Service mode for analog output [LT only]
1)
0...4,6 V at supply voltage 5 VDC; also valid for alarm output
2)
only at supply voltage ≥ 11 V
3)
inverted RS232, TTL, 9,6 kBaud
4)
500 mA if the mV output is not used
5)
High level: > 0,8 V/ Low level: < 0,8 V
6)
Reset of peak or valley hold by High level at IN/ OUT pin (Low: open or GND / High: >2,4 V...11 V)
7)
Reset of peak or valley hold by Low level at IN/ OUT pin (Low: GND / High: open or >1 V...11 V)
