6.4 Self Diagnostics
All Safety critical electronic components are monitored and stored in the Diagnostics log if
outside specification. In addition vibration, temperature and optical signals are analyzed and
stored in the Diagnostics log. The Diagnostics log is downloaded at the vendor during any
Service or inspection of the Detector. The Diagnostics log can also be downloaded by the user
and sent to the vendor for analysis and troubleshooting.
6.4.1 Downloading Self diagnostics datalog
1. Connect PC with Service software to modbus on terminals 4 and 5.
2. Start Service SW.
3. Follow instructions for Service SW to download diagnostics file from the Detector.
4. Store the Diagnostics file in a suitable place. The Diagnostics file can be sent to the
vendor for analysis.
Document 022-80036-OM Revision R03 Page 31 of 48
