Replacing the Motherboard (FRU)
Note – The hard drive backplane assembly is a eld-replaceable unit. It must be replaced by a
certied Oracle Service Technician.
■
“How to Remove the Motherboard” on page 73
■
“How to Install the Motherboard” on page 74
▼
How to Remove the Motherboard
See:
“Locations of Internal Server Components” on page 30
Backup motherboard (MB) FRUID information, see “How to Backup Motherboard FRUID
Information”on page 78
.
Prepare for service. See
“How to Prepare for Service”on page 21.
Remove the air duct. See
“How to Remove the Air Duct”on page 53.
Remove the SP module. See
“How to Remove the SP Module”on page 59.
Remove any PCIe cards. See
“How to Remove a PCIe Card”on page 40.
Remove the PCIe riser assembly. See
“How to Remove the PCIe Riser”on page 44.
Remove the DIMMs. See
“How to Remove a DIMM”on page 33.
Disconnect all cables attached to the motherboard and keep them clear of the motherboard.
See
“Sun Fire X2270 M2 Server Internal Cabling”on page 61.
If necessary label the cables.
Remove the CPU and heatsink assemblies. See
“How to Remove a CPU and Heatsink”on
page 67
.
BeforeYou Begin
1
2
3
4
5
6
7
8
9
Replacing the Motherboard (FRU)
73
