POWER MATCH
®
BAR NOSES (CONTINUED)
4. With the bar body, nose, and rivet solidly supported on a strong flat
metal surface, peen the Power Match
®
rivet’s head down with the flat
end of a hammer. Do not hit the bar body, hit only the rivet head. Strike
only on the “X" side; To ckeck installation, grip the bar body in one
hand, and twist. Nose and body should feel like a single, solid piece.
If not (if any movement in the nose-bar joint area is felt-or if any clicking
sound from the same area is heard), tighten the rivet with a few more
hammer strokes.
“X" Side Up
5. File down the rails of new noses to align with the rails of old bar
bodies.
6. Grease the new nose sprocket. Clean out guide-bar grease hole
before using lubricant. Pump grease into hole until excess grease
appears around the nose-sprocket teeth of the guide bar.
