Oregon CHAINSAW - Drive Sprockets; Sprocket Terms, Tools; And Installation

DRIVE SPROCKETS
66.
DRIVE SPROCKETS
DRIVE SPROCKETS
OREGON
®
SPROCKET TERMS
Clutch Drum
Clutch Skirt
Bore
Splined Hub/Adaptator
Rim Sprocket
Clutch Drum
Clutch Skirt
Bore
GREASE GUN
RIM SPROCKET
INSTALLING SPROCKETS
OREGON
®
sprockets can be installed on chainsaws having either
inboard-clutch or outboard-clutch assemblies. Follow instructions in
the operator’s manual provided by your chain saw’s manufacturer for
correct sprocket installation.
The illustration below are for general reference only. Do not use them
as instructions for sprocket or clutch assembly.
INBOARD CLUTCH
OUTBOARD CLUTCH
SPUR SPROCKET
OREGON
®
SPROCKET-MAINTENANCE TOOLS
