SAW CHAIN
49.
SAW CHAIN
SAW CHAIN
SAW-CHAIN TROUBLESHOOTING
PROBLEM
Chain cuts slow, cuts rough, or won’t hold an edge.
Most chain problems are caused by four things:
incorrect chain tension, incorrect filing, lack of lubrication, cutting any
material other than wood. Here are the things you should look for, and
the corrective actions you should take:
Look closely at your chain’s cutters, and compare them to the 12
illustrations below.
Light abrasive damage
on side plates.
Remedy: See A.
Severe abrasive dama-
ge on side plates.
Remedy: See A.
Abrasive or impact
damage to the top plate
or working corner.
Remedy: See A.
Too much top-plate filing
angle.
Remedy: See B.
Too little top-plate filing
angle.
Remedy: See B.
Too much top-plate-cut-
ting angle.
Remedy: See C.
Too little top-plate-cutting
angle.
Remedy: See D.
Too much hook in side
plate.
Remedy: See C.
Backslope on side plate.
Remedy: See D.
1 2 3
4 5 6
7 8 9
