OPERATING INSTRUCTIONS
15
6. Once the cutter is in the grind position and
the chain stop is in the desired position,
rotate the grind head/wheel down into the
grind position and adjust the appropriate
depth stop adjustment knob/wheel on the
lower left or right side of the motor (see
Figure 28).
7. With all initial adjustments made to the
grinder, connect the unit to the appropriate
power source (115 V electrical outlet or 12 V
external battery) depending on the unit
being used.
Figure 28
Figure 29
Figure 27
OFF
ON
Figure 26
