1.5. Dimensions and weights
Figure 1.6. cgmcosmos dimensions
Module
Height (h)
[mm]
Width (a)
[mm]
Depth (f)
[mm]
Bushings height (g)
[mm]
Weight
[kg]
-l
[2] [3] [4]
1300
365 735
725 90
1740 1165 100
-p
1300
470 735
410 140
1740 850 150
-v (RAV)
1740 480 845 695 240
-2lp
[2] [3]
1300
1190 735
Feeder Fuse protection
290
725 410
1740 1165 850 310
The weight refers to the enclosure, with no metering transformer inside.
[2]
In the case of dual symmetric terminal, the depth of the switchgear increases by 200 mm and the weight by 5 kg, per feeder function.
[3]
In the case of symmetric terminal plus symmetric surge arrester, the depth of the switchgear increases by 200 mm and the weight by 5 kg, per feeder
function.
[4]
For exterior cable test device, please check with Ormazabal.
Table 1.1. Dimensions and weights
IG-296-EN version 01; 12/03/2020
11
General instructions
cgmcosmos: Medium voltage cubicles with full insulation
in SF
6
gas up to 24 kV in accordance with IEC Standard
General description
