2. Handling and transport
[3]
Position the rear of the cubicle facing the driver, to avoid damaging the front.
Important: During transport, the switchgear must
be perfectly seated and xed so that it cannot move
about and possibly damage the equipment.
2.1. Lifting means
The switchgear must always be kept upright, directly on the
ground or on a pallet depending on the type of handling
involved.
One of the following methods must be used for assemblies
of up to 4 cgmcosmos functional units:
1. Using a forklift truck or pallet jack.
[3]
Figure 2.1. Lifting a cgmcosmos cubicle with a fork-lift truck
IG-296-EN version 01; 12/03/2020
13
General instructions
cgmcosmos: Medium voltage cubicles with full insulation
in SF
6
gas up to 24 kV in accordance with IEC Standard
Handling and transport
