4.8. Cable connections
[9]
It is advisable to use fully insulated connectors for voltages of 24 and 17.5 kV, according to HD 629.
The medium voltage incoming and outgoing feeders are
linked to the transformer or, occasionally, other cubicles
via cables. These cables and the corresponding bushings
on the cgmcosmos system cubicles can be connected with
simple (plug-in) or reinforced (screw-in) connecting points,
either IEC type or IEEE-386 compliant.
The cable compartment contains the connecting cable
bushings for the incoming and outgoing feeders, as well as
for the outgoing feeders to the transformer.
The size of the cable compartment allows the use of both
insulated and partially insulated terminals.
[9]
Never touch live connectors, not even screened
connectors. Screening does not constitute a protection
against direct contact.
When the equipment is in service and a reserve cubicle
is left with voltage in the upper busbar and without the
cables in the lower bushings, insulating plugs must be
placed in the bushings (EUROMOLD type) or close the
earthing switch and lock that position with a padlock.
The recommended terminations are described below.
Rated
current
[A]
Manufacturer Connector
12 kV 24 kV
Connector
type
Section
[mm
2
]
Connector
type
Section
[mm
2
]
250
EUROMOLD(*) Screened
Angled 158LR 16 - 150 K-158LR 16 – 150
Straight 152SR 16 - 120 K-152SR 25 - 120
3M Screened Angled 93-EE-8XX-2 25 - 95 93-EE-8XX-2 25-95
F & G Screened Angled ASW 10/250 25 - 120 ASW 20/250 25 – 120
KABEL-DRAHT Screened
Angled SEHDW11 25 - 150 SEHDW21 25 – 250
Straight SEHDG11 25 - 150 SEHDW21 25 - 150
PFISTERER Screened Angled CAW 20/250 35 - 70 CAW 20/250 35 - 70
PIRELLI Screened
Angled PMA-1-250/25 25 - 95 PMA-1-250/25 25 – 95
Straight PMR-1-250/25 25 - 95 PMR-1-250/25 25 – 95
RAYCHEM Screened
Angled RSES 16 – 120 RSES 16 – 120
Straight RSSS 16 - 95 RSSS 16 – 95
400
3M Unscreened 93-EE-8XX-2 25 - 95 93-EE-8XX-2 25 - 95
EUROMOLD(*) Screened
400LR 70 - 300 K-400LR 25 - 300
400TE 70 - 300 K-400TE 25 – 300
F & G
Screened
AST 10/400 25 - 240 AST 20/400 25 - 240
ASW 10/400 25 – 240 ASW 20/400 25 - 240
ASTS 10/630 120 - 240 ASTS 20/630 25 - 240
Unscreened
AGL 10/630 120 - 240 - -
AGLS 10/630 120 - 240 - -
AWK 10/630 25 – 240 ASGS 10/630 25 – 240
AWKS 10/630 25 – 240 AWKS 20/630 25 – 240
KABELDON Unscreened KAP 300 10 - 300 - -
KABEL-DRAHT
Screened
SEHDW12 35 – 185 SEHDW22 25 – 250
SEHDT12 35 – 150 SEHDT22 35 – 150
SEHDW12 35 – 185 SEHDW22 25 - 250
Unscreened - 25 - 150 SEHDG23 185 - 240
PIRELLI Screened
PMA-2-400/24 25 – 95 PMA-2-400/24 25 - 95
PMR-2-400/24 50 – 300 PMR-2-400/24 50 – 300
PMA-3-400/24 25 - 240 PMA-3-400/24 25 - 240
RAYCHEM Unscreened
UHGK+RICS 120 – 300 UHGK+RICS 95 – 240
IXSU+RICS 16 – 800 IXSU+RICS 16 – 800
