4.8.1. Horizontal front connection
1. Close the earthing switch.
2. Remove the cover to access the cable compartment.
Figure 4.22. Cable compartment detail
3. Connect the terminals on the front bushings and secure
the cables using the cable support and clamp.
The clamp has two positions, depending on the cable
diameter.
Figure 4.23. Terminal connection detail
IG-296-EN version 01; 12/03/2020
31
General instructions
cgmcosmos: Medium voltage cubicles with full insulation
in SF
6
gas up to 24 kV in accordance with IEC Standard
Installation
