4. Open the bottom cover to access the cable compartment.
Figure 5.21. Cable compartment cover opening
5. Turn the handle on the fuse holder cover upwards to
disengage the locking clip and pull rmly outwards.
Figure 5.22. Fuse-holder opening
6. Press the safety trigger.
Figure 5.23. Pressing the safety trigger
IG-296-EN version 01; 12/03/2020
47
General instructions
cgmcosmos: Medium voltage cubicles with full insulation
in SF
6
gas up to 24 kV in accordance with IEC Standard
Recommended sequence of operations
