Orolia EdgeSync User Manual

orolia.com EdgeSync Manual rev 1 | 47
Verify that the PTP Grand
Master is providing PTP Timing
messages
MCE synchronization loop
control system has not
converged to the input timing
source.
Wait 2 to 15 minutes for the
MCE to converge and
synchronize to the input timing
source.
EdgeSync Alarm condition is
affecting MCE synchronization.
Check the Alarms/Events Tab
Webpage for information about
any EdgeSync alarms that
might affect MCE
synchronization.
Symptom Probable Cause Recommended Action
Home Webpage – GNSS 1 PPS
Status Unstable/Unavailable
GNSS input signal from
Antenna and cable is missing or
weak.
Verify that the GNSS Antenna
coax is securely plugged into
the SMA port.
Verify that the GNSS Antenna
signal is present.
GNSS Antenna / cable
configuration does not meet
requirements of the
Antenna
input Section.
Verify that the GNSS Antenna /
cable meets requirements of
the
Antenna input Section.
EdgeSync Alarm condition is
affecting inputs from the GNSS.
Check the Alarms/Events Tab
Webpage for information about
any EdgeSync alarms that
might affect GNSS input signals.
Symptom Probable Cause Recommended Action
Home Webpage – GNSS ToD
Status Unstable/Unavailable
GNSS input signal from
Antenna and cable is missing or
weak.
Wait approximately 2 minutes
for the MCE processor to
complete booting.
GNSS Antenna / cable
configuration does not meet
requirements of the
Antenna
input Section.
Verify that the GNSS Antenna /
cable meets requirements of
the
Antenna input Section.
The user has selected external
1PPS / ToD inputs but has not
connected the input sources.
On the EdgeSync Front Panel,
connect the 1PPS / ToD RJ45
input source. On the
Interface ::
GNSS
web page, Enable 1PPS
In and ToD In.
