932502G / 0618 7. FIRMWARE COMMANDS AND RESPONSES
SHOW_GAIN_COARSE
Returns the coarse gain for the DSPEC 50 internal amplifier. In operation, the resulting
signal gain is the product of the coarse gain, the fine gain, and the super-fine gain (used by
stabilizer). The coarse gain is returned in terms of an integer gain multiplier.
Responses:
$C00001088<CR> Coarse gain reported as 1.
$C00002089<CR> Coarse gain reported as 2.
$C00004091<CR> Coarse gain reported as 4.
$C00008095<CR> Coarse gain reported as 8.
$C00016094<CR> Coarse gain reported as 16.
$C00032092<CR> Coarse gain reported as 32.
$C00064097<CR> Coarse gain reported as 64.
$C00128098<CR> Coarse gain reported as 128.
SHOW_GAIN_CONVERSION
This command returns the conversion gain.
Responses:
$C00512095<CR> Conversion gain reported as 512 channels.
$C01024094<CR> Conversion gain reported as 1024 channels.
$C02048101<CR> Conversion gain reported as 2048 channels.
$C04096106<CR> Conversion gain reported as 4096 channels.
$C08192107<CR> Conversion gain reported as 8192 channels.
$C16384109<CR> Conversion gain reported as 16384 channels.
SHOW_GAIN_FINE
Returns the current fine gain setting. See SET_GAIN_FINE.
Sample Response:
GAIN_FINE 000000.70000203 Fine gain is set to 0.7.
SHOW_GAIN_POLARITY
Returns the polarity of the amplifier input as $F records.
Responses:
$FNEG<CR> The amplifier input is set to negative.
$FPOS<CR> The amplifier input is set to positive.
SHOW_GAIN_STABILIZATION
Reports the state of gain peak stabilization. See also ENABLE_GAIN_STABILIZATION
and DISABLE_GAIN_STABILIZATION.
Responses:
$IT<CR> Gain stabilization is currently enabled.
$IF<CR> Gain stabilization is currently disabled.
105
