DSPEC 50
®
and DSPEC 502
®
Digital Gamma-Ray Spectrometer User’s Manual 932502G / 0618
If you forget the password:
! See the reset instructions in Section B.3.
2.1.4.2. Regional Settings...
This accesses the DSPEC 50 computer’s Windows Mobile regional settings utility. (You may
wish to use a touchscreen stylus to change these settings.) Tap Regional Settings, choose the
desired locale, and tap OK. This will return you to the Communication Control screen. Tap
Apply to put the new settings into effect and return to the Switchboard.
To modify the settings for the current locale, tap Customize. The locale list does not include Far
East settings; choose a locale and customize the settings as needed. For additional information,
refer to the Microsoft website.
2.1.5. The Data Display Screens
Each MCA in the chassis has four data display screens that track various data acquisition
parameters in real time. All four display the following:
! The current time (Now); the start time for the current or most recent acquisition
(Started); and, at the end of acquisition, the stop time of the most recent acquisition
(Finish).
! A red HV Off indicator ( ) when the bias is off.
! A bright background when data acquisition is in progress, and a neutral background
when acquisition is stopped.
In addition, the two sets of four DSPEC 502 screens are labeled MCA-1 and MCA-2 so you can
easily tell which input is currently being displayed.
Use the Display Control screen to display/hide these screens, and set the display order and
display interval (Section 2.1.3).
2.1.5.1. The Gauges Screen
This screen gives you a “heads-up” display of % of preset remaining, Dead time %, and Input
count rate in cps. Below each gauges is a corresponding text readout (except that no matter the
type of preset used, the left-side text readout shows the live time, LT).
When no presets are defined, the % Preset gauge remains at zero and the LT text readout shows
the current live-time count.
22
