932502G / 0618 7. FIRMWARE COMMANDS AND RESPONSES
SHOW_TRIGGER_SAMPLE
Reports the trigger source in Insight Mode.
Responses:
$F0LLD LLD is source.
$F1PKD Peak-detect is source.
$F2RANDOM Trigger happens randomly.
$F3Gate Gate Input triggers the waveform.
SHOW_TRUE
Reports the contents of the true-time counter in units of 20 ms (50 ticks/s). See also
CLEAR_COUNTER and SET_TRUE.
Responses:
$G0000000000075<CR> True time reported as 0 ticks.
$G0000000001076<CR> True time reported as 1 tick (20 ms).
... ...
$G4294967295132<CR> True time reported as 4294967295 ticks (over 23000
days).
SHOW_TRUE_PRESET
Reports the current true-time preset in units of 20 ms (50 ticks/s). See also
CLEAR_PRESETS and SET_TRUE_PRESET.
Responses:
$G0000000000075<CR> True time preset reported as disabled.
$G0000000001076<CR> True time preset reported as 1 tick.
... ...
$G4294967295132<CR> True time preset reported as 4294967295 ticks.
SHOW_TRUE_REMAINING
Reports the current true time remaining in units of 20 milliseconds (50 ticks per second). See
also SET_TRUE_REMAINING.
Responses:
$G0000000000075<CR> True time remaining reported as disabled.
$G0000000001076<CR> True time remaining reported as 1 tick.
... ...
$G4294967295132<CR> True time remaining reported as 4294967295 ticks.
SHOW_ULD
Returns the value of the ULD in channels, as a $C record.
117
