932502G / 0618 7. FIRMWARE COMMANDS AND RESPONSES
MODE_ZDT NORM_CORR CORR_ERR Mode 0 stores the normal and corrected
spectra. Mode 1 stores the corrected and
the error spectra.
LIST_OUTPUT_WIDTH
Lists the valid output width settings.
Response:
OUTP_WIDT 0 16 0 16000 0 to 16 seconds with up to 16000 steps of 1 ms
LIST_ROI_SAMPLE
Lists the valid ROI sample settings.
Response:
ROI_SAMP PUR BLN BLRG BLD BUSY GATE RESV PKDET
LIST_SHAP_CUSP
Not used by the DSPEC 50; included for backward compatibility.
LIST_SHAP_FLAT
Lists the valid flattop width settings.
Response:
SHAP_FLAT 0.3 2.4 3 24 Settings are 0.3 to 2.4 in 22 steps of
0.1 ìs.
LIST_SHAPE_RISE
Lists the valid rise-time settings.
Response:
SHAP_RISE 0.8 23.0 4 115 Settings are 0.8 to 23 in 0.2-ìs steps.
LIST_SHUT
Lists the valid shutdown settings.
Response:
SHUTDOWN TTL ORTEC SMART
LIST_TIME_ETP
Returns the range of valid protection-time settings in the Enhanced Throughput Mode.
Response:
TIME_ETP 01 200 4 8000 Valid settings range from 0.1 ìs to 200 ìs in 25-ns
increments.
LIST_TRIGGER_SAMPLE
Lists the valid trigger sources in Insight (sample) mode.
Response:
TRIG_SAMP LLD PKD Random Gate
89
