23
3 Function and external components
3.1 Fundamental operating principle
The control unit changes/switches the lighting at workplaces, in corridors and other common
rooms depending on the usable daylight and the presence/motion of persons. This is recorded by
sensors. This increases working comfort and saves energy. There are function modes for various
applications/scenarios
8 .
These can be adapted individually 5.
3.2 DALI 1 / DALI 2 twin-channel control
The luminaires can be operated with identical light values or with OFFSET for CH-2 after electrical
installation to the DALI 1 (CH-1) and DALI 2 (CH-2)
5.10.
3.3 External push-button
4
Actuation of an external push-button has priority over automatic functions.
3.4 Behavior after mains interruption
Depending on the set function mode, the system is in preset condition when mains voltage is
restored:
Operating mode Condition
Single Office OFF
Open Plan Office OFF
Corridor STANDBY
Meeting room/classroom LAST STATE
Sanitary Room STANDBY
Staircase STANDBY
No operating mode selected LAST STATE
4 Operation
Description of all push-buttons/LEDs of the Master Remote and its functions that do not require
use of the [PROG] push-button, and description of all push-buttons/LEDs of the User Remote
and their basic functions.
4.1 Master Remote remote control 7 (and separate instructions)
Push-buttons / LEDs / connections
(1) [ON/OFF] Lighting on/off
(2) Signalization LED 1 (green/red/orange)
(3) [test] Test mode for setting detection range (1 second delay time)
(4) [Function modes] selection
(5) [PROG] Programming mode on/off
(6) [100 h Burn-in] on/off
(7) [Auto setup] Activation of automatic set value saving
(8) [CH-1] Setting brightness on channel 1 (manual/direct)
(9) [Stand-by-time] Selection of STANDBY time defaults
(10) [Sensor select] Sensor selection
(11) Signalization LED 2 (green/red/orange)
(12) [Switch off delay] Selection of delay time defaults
(13) [Macro Recorder] Recording/saving/sending push-button sequence
(14) [Offset] Setting OFFSET on/off
(15) [PC modes] No function
(16) [CH-2] Setting brightness on channel 2 (manual/direct)
(17) [Manual setup] Manual light value setting
(18) [Stand-by-level] Selection of STANDBY defaults
(19)
/
Selection of daylight/motion sensor functions on/semi-automatic/off
(20) Connection USB mini
Signalization LEDs
• LED 1 - flashes rapidly during signal transfer (IR) (green)
• LED 1 - flashes in "PROG" mode (red)
• LED 1 - lights up during USB transmission (orange)
• LED 2 - flashes in "Sensor Select" mode (green)
• LED 1/LED 2 - lights up during "Reset" Master Remote (orange)
