Osram DALIeco Control User Manual

28
6.4 Independent operation of several systems
Teaching of the User Remote to a specific selected receiver in order to permit independent
operation of several systems (maximum 15) in the same room.
1. Simultaneously press push-buttons [CH-1 ] + [CH-2 ]
(VLP) to start individual programming (LED flashes red).
2. Activating number block (factory setting = 16):
- Number block 1-4: Press push-button [1] (SP).
- Number block 5-8: Press push-button [2] (SP).
- Number block 9-12: Press push-button [3] (SP).
- Number block 13-16: Press push-button [4] (SP).
3. Programming system number:
- Press push-button [1], [2], [3] or [4] (SP) for the system
number to be programmed (factory setting = 16) (LED
flashes green twice and system flashes in confirmation).
--> Example: Programming system number 10:
1. Simultaneously press push-buttons [CH-1 ] + [CH-2 ] (VLP) (LED flashes red).
2. Press push-button [3] (SP) to activate number block 9-12.
3. Press push-button [2] (SP) to program system number 10
(LED flashes green twice and system flashes in confirmation).
7 Reset
7.1 System reset (using Master Remote)
1. Press push-button [PROG] (LP) to start programming mode (LED1 flashes).
2. Press [Single Office] (SP) to set default function mode (LED1 flashes rapidly).
3. Press push-button [PROG] (SP) to exit programming mode.
7.2 Reset Master Remote
1. Press push-button [PROG] (LP) to start programming mode (LED1 flashes).
2. Simultaneously press (VLP) [Corridor] and [Staircase] (LED2 flashes).
3. Press push-button [PROG] (LP) – (LED1 and LED2 light up orange for 3 seconds).
7.3 Reset User Remote
1. Simultaneously press (VLP) [CH-1 ▲] and [Resume] (LED flashes red).
2. Press push-button [4] (SP) – (LED lights up orange for 3 seconds).
8 Technical data
Mains connection 220 – 240 V AC 50-60 Hz
Push-button input Floating NO contacts,
Max. line length 50 m
Load (control) outputs DA1+/- /DA2+/- In accordance with IEC 62386 ditto.
Control current Max. 64 mA (per channel)
Max. 96 mA (sum of both channels)
Max. cable length 100 m (per channel)
Sensor system connection DALIeco LS/PD LI = max. 4x
DALIeco LS/PD LI HF = max. 1x
Max. line length 25 m, with
extension/shortening ensure
contact allocation 1:1
Power consumption 0.2 W - 3.0 W (depending on
ECG/number of sensors)
Ambient temperature -20 °C to +50 °C (operation)
Type of protection IP20
Protection rating II, protective insulation
Conformity CE
i
Important note:
If it is not possible to route the sensor lines and push-button lines of the sensors and
push-buttons that are directly connected to the control unit separately from the mains
and lamp lines, then we recommend incorporating the sensors and push-buttons via
the DALI line.
CH-2
CH-1
1
3
2
4
Holiday
Resume
