OTICON AGIL FITTING GUIDE
41
Connecting Oticon Agil to Genie
Oticon Agil is programmed using the Genie fitting
software compatible with NOAH 3.0 and Oticon
programming cable #3 (right and left)
The table shows how to connect
the different styles when fitting with cables
Instrument Style Programming Interface
miniRITE Flex Connect
BTE/RITE Programming Shoe
ITC/ITE Programming Adapter
CIC/MIC Flex Connect
6
Connecting Flex Connect to miniRITE
1. Open the battery door on the instrument and slide
the Flex Connect into the instrument as shown
(pointing the black dot on the cable upwards).
Insert a fresh battery.
2. Close the battery door and attach the HI-PRO or
NOAHlink cable.
Connecting the Programming Shoe
to BTE and RITE
1. Open the battery door on the instrument and slide
the programming shoe into the guide as shown.
Insert a fresh battery.
2. Close the battery door and attach the HI-PRO or
NOAH link cable.
1
2
1
2
