Performing the Guided Accuracy Test
䡵 Loosen the three knurled screws at the pipe housing.
䡵
Remove the pipe housing upwards.
䡵 Remove both spring-loaded terminals and carefully remove the collecting bucket.
䡵 Remove the USB interface cover and connect the OTT Pluvio
2
S to the PC via
the USB cable (included); refer to Fig. 21.
䡵 Start the OTT Pluvio
2
S Operating Software.
䡵
Select the “Connect” button ➝ the Operating Software will establish a con -
nection to the OTT Pluvio
2
S unit and retrieves different status information.
䡵 Select the “Guided Accuracy Test” button ➝ a wizard will guide you through
the accuracy test. Make sure you follow all the steps and notes shown on
t
he display!
䡵 After completing the accuracy test, remove the USB cable.
䡵 Replace the USB interface cover.
䡵 Empty the collecting bucket as necessary, reinstall it and secure it using the
two spring-loaded terminals; refer to Fig. 17.
䡵 Align the pipe housing and install it, refer to Fig. 20.
䡵 Retighten three knurled screws.
Please note: After attaching the USB interface, the OTT Pluvio
2
S disconnects
communication over the other interfaces!
43
