66
7.20 Thoracic Supports
Loosen the knurled nuts to adjust the supports to reduce or increase the free space for the body
and for height adjustment of the supports. It is also possible to adjust the height of the supports
by loosening and shifting the Allen head screws (
Fig. 51, item A). Finally, attach the pads to the
supports and close the hook & loop straps.
51
A
A
7.21 Buggy Board
The buggy board (Fig. 49) allows children to ride safely while standing on their own feet and
offers sufficient standing room. For attaching the buggy board to the outdoor mobility base
(Fig. 50) and adjusting the buggy board length, width, height and angle, follow the manufacturer’s
instructions for use provided.
Danger!
The maximal load capacity of the buggy board is 30 kg (66 lbs). There is risk of
injury when overloaded.
52 53
