70
*Attention!
Mobility bases and seating units have different load capacities.
Example A:
Seating unit (max. 35 kg/77 lbs) + own weight of the seating unit, size 1 (7 kg 15.5
lbs) = 42 kg/92.5 lbs
Mobility base (max. 50 kg/110 lbs) – fully loaded seating unit (42 kg/92.5 lbs)
= 8 kg/18 lbs for other accessories
Example B:
Twin outdoor mobility base (max. 50 kg/110 lbs) - 2x seating unit (14 kg/31 lbs) =
36 kg/79 lbs (18 kg/39.5 lbs each child incl. accessories)
11 Information on Re-use
Danger!
Risk due to improper use. Seat paddings which come into direct contact with the
skin may cause functional or hygienic risks for another patient using one and the
same product. They should be replaced in case of re-use.
The product is suitable for re-use.
Similar to second-hand machines or cars, products that are being re-used are subject to increased
strain. Features and functions must not change in a way that could endanger patients or other
persons within the product’s life cycle. Based on market observations and the current state of
technology, the manufacturer has calculated that the product drive can be used for a period of
4 years
, provided that it is used properly and that the service and maintenance instructions are
observed. Periods during which the wheelchair is stored at the dealer or with the cost bearer are
not included in this period. It should be clearly pointed out, however, that the product is reliable far
beyond this defined period of time, provided that it is cared for and maintained appropriately.
In cases of re-use, the corresponding product must first be thoroughly cleaned and disinfected.
Afterwards, the condition of the product must be examined by an authorized dealer to check for
wear and tear as well as any damage. Any worn and damaged components as well as compo-
nents which do not fit or are unsuitable for the new user must be replaced.
The service manual includes a service schedule, detailed information, and a list of the required
tools.
