2 Sensor
2.1 Overview
The Rev7 OS0 offers an industry-leading combination of price, performance, reliability, size, and
weight. Itisdesignedforindoor/outdoorall-weatherenvironmentsandalonglifetime.
The Rev7OS0 family of sensors consist of three models, theRev7OS0-128, Rev7OS0-64, and Rev7
OS0-32,withdifferingverticalresolution,butidenticalmechanicaldimensions.
For the purposes of this document, the term “OS0” refers to the family of sensors, and only where
thereisadifferenceinperformancewilleachmodelbereferredtobyitsspecificmodeldesignation.
ThecontentsofthismanualareapplicableonlytoRev7sensors. Pleasefindthestickeronthetopcap
orthebottomofthesensorthatwillhavealltheinformationregardingproduct type,serial number and
part number. For all other sensor hardware revisions, please refer to their respective hardware user
manual.
2.2 OS0ProductModels
TheRev7OS0isavailablewith128,64,or32beamsofverticalresolutionandwithUniform,Gradient,
AboveHorizon,orBelowHorizonbeamspacingoptions. Productspecsandmoreinformationonthese
configurationscanbefoundontheOS0productpage.
3 MechanicalInterface
3.1 IncludedComponents
TheRev7OS0isshippedwiththefollowingitems:
Sensor
Interfaceboxcable/connector
24VAC/DCpowersupply(2meters)
RJ45cable(1meter)
BaseplateMount
