Lorsd’une utilisationàtempératureambiantesupérieureà 40°C,lasurfacemétalliqueducap-
teurpeutprésenterdesrisquesdebrûlurespourlapeau. Dans ces conditions, ilestimportant
d’éviter tout contact avec la partie supérieure, la base ou le dissipateur thermique du capteur.
Le capteur ne doit pas être utilisé à une température ambiante supérieure à 60˚C. 60˚C est la
températuremaximalecertifiéed’opérationsûreducapteur.
Equipment Label: Includes model and serial number and a notice that states the unit is a Class 1
LaserProduct,isaffixedonthebaseextension. Itisonlyvisibleaftertheattachedmountwithwhich
theSensorisshipped,isremoved. ForlocationdetailspleaserefertofigureSensor Components(Me-
chanical Drawings) intheMechanicalInterfaceSection.
L’étiquettedel’équipement,comprenantlemodèle,lenumérodesérie,etlaclassificationduproduit
laser (ici, classe 1),est apposée au-dessous delabase du boîtier du capteur. Il n’est visible qu’après
avoirretiréle diffuseur de chaleuraveclequellecapteurest expédié. L’emplacementestdécritavec
précisiondanslasectionSensor Components (MechanicalDrawings).
Electromagnetic Compatibility: The Rev7 OS0 is an FCC 47 CfR 15 Subpart B device. This device
complies with part 15 of the FCC Rules. Operation is subject to the following conditions: (1) This
devicemaynotcauseharmfulinterference,and(2)thisdevicemustacceptanyinterferencereceived,
includinginterferencethatmaycauseundesiredoperation.
“Ouster”and“Rev7OS0”arebothregisteredtrademarksofOuster,Inc. Theymaynotbeusedwithout
expresspermissionfromOuster,Inc.
Ifyouhaveanyquestionsabouttheabovepoints,contactusatOusterLegal.
1.2 ProperAssembly,MaintenanceandSafeUse
TheRev7OS0canbeeasilysetupbyfollowingtheinstructionsoutlinedinMounting Guidelines. Any
mountingorientationisacceptable. Eachsensorisshippedwithanattachedmountthatcanbeused
fortestornormalusewithinthespecifiedoperatingconditions. Thesensormayalsobeaffixedtoany
otheruserspecificmountofappropriatethermalcapacity. PleasecontactOusterforassistancewith
approvingtheuseofuserspecificmountingarrangements.
Any attempt to utilize the sensor outside the environmentalparameters delineated in the Rev7OS0
datasheetmayresultinvoidingofthewarranty.
When power is applied, the sensor powers up and commences boot-up with the laser disabled. The
boot-upsequenceisapproximately60sinduration,afterwhichtheinternalsensoropticssubassem-
blycommencesspinning,thelaserisactivated,andtheunitoperatesinthedefault1024x10Hzmode.
Whenthesensorisrunning,andthelaserisoperating,afaintredflickeringlightmaybeseenbehind
theopticalwindow.
Note that the Rev7 OS0 utilizes an 865nm infrared laser that is only dimly discernible to the naked
eye. The sensor is fully Class 1 eye safe, though Ouster strongly recommends against peering into
theopticalwindowatcloserangewhilethesensorisoperating. Ouster sensorsareequippedwitha
multi-layerseriesofinternalsafetyinterlockstoensurecompliancetoClass1LaserEyeSafelimits.
The Rev7 OS0 is a hermetically sealed unit, and is not user-serviceable. Any attempt to unseal the
enclosurehasthepotentialtoexposetheoperatortohazardouslaserradiation.
6
