Example: GPSModulecompatiblewithOusterSensorGPSModule. Ifyouneedsupporttoconfigure
theGPStoworkswithoursensorpleasecontactsupport@ouster.io.
Warning: RISK OF FIRE OR ELECTRIC SHOCK. DO NOT CONNECT THE GPS CONNECTOR DI-
RECTLYTOANANTENNA.
InterfaceBox–Important Notice
The Ouster Interface Boxis a support tool for use in laboratory environments to assist customersin
evaluating Ouster’s lidar sensor products and in the development of software. The Interface Box is
notprotectedfromingressofmoistureorsolidparticlesandisnotintendedforuseoutdoor.
TheInterfaceBoxhasa top coveraffixedusing4self-tappingscrews. Thecovermay need tobere-
moved in order to set the operating modes or to change the fuse. The plastic that the self-tapping
screwsfastenintoisdelicate,pleaseremoveandreplacethescrewsslowlyandcarefully. Whenmul-
tipleattemptsaremadetoremovethescrews,themountingpostsmaybestripped.
Figure 7.2: WarningonSelfTappingScrews
24
