Figure 1.3: Thissymbolindicatesthatthesensoremitslaserradiation.
Figure 1.4: Thissymbolindicatesthepresenceofahotsurfacethatmaycauseskinburn.
CAUTIONS:
TheRev7OS0isahermeticallysealedunit,andisnonuser-serviceable.
Useofcontrols,oradjustments,orperformanceofproceduresotherthanthosespecifiedherein,
mayresultinhazardousradiationexposure.
Useof the Rev7OS0issubject totheTermsof Sale that you agreedand signed with Ouster or
yourdistributor/integrator. Includedinthesetermsaretheprohibitionsof:
Removingorotherwiseopeningthesensorhousing
Inspectingtheinternalsofthesensor
Reverse-engineeringanypartofthesensor
Permittinganythirdpartytodoanyoftheforegoing
Operatingthesensorwithoutthe attached mount that is shippedwiththesensor,orattaching
the sensor to a surface of inappropriate thermal capacity runs the risk of having the sensor
overheatundercertaincircumstances.
Thislidarsensorfeaturesamodularcapdesigntoenablemoreflexiblemountingandintegration
solutionsforthesensor.
The modular cap design increases design flexibility but it does not remove the need for ther-
mal management on top of the sensor. The attached radial cap serves an important thermal
managementpurposeandthesensorwillnotoperateproperlywithoutacap.
Operationforextendedperiodsoftimewithoutthecapwillresultinsystemerrorsandthesen-
sor overheating. The cap can be replaced with alternative solutions but it cannot be left off
altogether.
Ifyouwishtooperatethesensorwithacustommountingsolution,pleasecontactourFieldAp-
plication Team and we can answer your questions and provide guidance for achieving proper
operations.
