4.Advanced User Guidebook
Recall or close the waveform stored in
the current object address. When the
show is ON, if the current object
address has been used, the stored
waveform will be shown, the address
number and relevant information will be
displayed at the top left of the screen; if
the address is empty, it will prompt
"None is saved".
Close all the waveforms stored in the
object address.
Save the waveform of the source to the
selected address. Whatever the Type
of save menu is set, you can save the
waveform by just pressing the Copy
panel button in any user interface.
Select Type in the bottom menu, in the
right Format menu, you can select the
storage format.
Save to internal storage or USB
storage. When External is selected,
save the waveform according to the
current record length (see "Record
Length menu" on P49); the file name is
editable. The BIN waveform file could
be open by OWON waveform analysis
software (on the supplied CD).
When the type is Configure, the menu shows as following:
Save the current oscilloscope configure
to the internal storage
Recall the configure from the selected
address
When the type is Image, the menu shows as following:
Save the current display screen. The
file can be only stored in a USB
storage, so a USB storage must be
connected first. The file name is
editable. The file is stored in BMP
format.
Save and Recall the Waveform
