4.Advanced User Guidebook
and storage function. The storage medium contains two kinds: Internal and
External.
When the storage medium is Internal, Wave Record contains four modes: OFF,
Record, Playback and Storage.
When storage medium is External, Wave Record contains two modes: OFF,
Record.
Record: To record wave according to the interval until it reaches the end frame
set.
Record menu (Internal Storage) shows as follows:
OFF
Record
Playback
Storage
Close wave record function
Set record menu
Set playback menu
Set storage menu
Click or to select the number of frames to
record (1 - 1000)
Click or to select the interval between
recorded frames (10ms - 10s)
Refresh wave during recording
Stop refreshing
Begin to record
Stop recording
Note:
Both of the waveforms of Channel 1 and Channel 2 will be recorded. If a
Channel is turned off while recording, the waveform of the channel is invalid in
the playback mode.
Playback: Play back the wave recorded or saved.
Playback menu shows as follows:
Click or to select the number of start
frame to playback (1 - 1000)
Click or to select the number of end
frame to playback (1 - 1000)
Click or to select the number of current
frame to playback (1 - 1000)
Click or to select the interval between
played back frames (10ms - 10s)
Play back the wave continuously
Play back the wave just one time
To Next Page
