4.Advanced User Guidebook
Begin to record
Stop recording
Storage: Save the current wave according to the start frame and end frame
set.
Storage menu shows as follows:
Click or to select the number of start
frame to store (1 - 1000)
Click or to select the number of end
frame to store (1 - 1000)
Save the waveform record file to the internal
memory
Load the waveform record file from the memory
To use wave record function, do as follows:
(1) Click to call up the menu panel. Click the Save softkey on panel.
(2) Select Type in the bottom menu, in the left menu, select Record.
(3) Select Mode in the bottom menu, select OFF in the right menu.
(4) In the bottom menu, select Storage as Internal.
(5) Select Mode in the bottom menu, select Record in the right menu.
(6) Select FrameSet in the bottom menu, set End frame and Interval in the
right menu.
(7) In the bottom menu, set Refresh.
(8) In the bottom menu, select Operate as Play.
(9) Select Mode in the bottom menu, select Playback in the right menu. Set
FrameSet and Playmode, select Operate as Play.
(10) To save the wave recorded, select Mode in the bottom menu, select
Storage in the right menu. Select FrameSet in the bottom menu to set the
range of frames to store, select Save in the bottom menu.
(11) To load the waveform from the internal memory, select Load in the bottom
menu, then enter the Playback of the Mode to analyze the wave.
Note: When playbacking the waveform, the sampling, trigger, or display
function is not available.
When storage medium is External, Wave Record contains two modes:
OFF, Record.
Record menu (External Storage) shows as follows:
Close wave record function
Set record menu
Click or to select the number of frames
to record (1 – 900,000)
To Next Page
