Double - sided Tape
ESC
Accessories Bag
Step 2
Step 3
Battery wires
Motor wires
Use 3 x cable ties, to hold Throttle ESC wire to main frame. Use Frame built-in socket for best holding.
In this Step connect Motor and ESC Wires but don't fix. Wait the final motor rotation check, once FBL system
will set. NOTE: To reverse Motor rotation direction , just switch 2 of the 3 wires.
Step 1
Page 16
Install the ESC as shown, and secure
with cable ties 2.5mm.
Chapter 11, ESC Installation
