Oxy Heli oxy3 - Chapter 12, Flybarless Installation

Double - Side Tape
Flybarless Unit
Servo Ports
Forward
FBL system can install in bottom or
top boom clamp, we suggest to
use the bottom install for easy
wiring and servo remove.
For extra FBL support we
suggest to add Electronic
Hook and Loop as shown.
Step 1 Step 2
Page 17
Chapter 12, Flybarless Installation
