Paccar MX-13 Programming Guide

PEC017
5/3/2018 Page 101 of 105
N102
Page 45
Min
Default
Max
Units
Signal Source for Remote Main
Switch
0
0
1
N/A
GP13
Page 68
Min
Default
Max
Units
GDP Last Gear Active
GP11
N/A
NOT
TOP
GEAR
GEAR #
GP14
Page 68
Min
Default
Max
Units
GDP Active Gear Count
N/A
N/A
N/A
N/A
PS25
Page 67
Min
Default
Max
Units
PGS Speed Step Count
0
N/A
2
N/A
PS26
Page 67
Min
Default
Max
Units
PGS First Limit Gear Min
1
N/A
<PS28
GEAR #
PS27
Page 68
Min
Default
Max
Units
PGS First Engine Speed Limit
1400
N/A
PS29
RPM
PS28
Page 67
Min
Default
Max
Units
PGS First Limit Gear Max
>PS26
N/A
<PS30
GEAR #
PS29
Page 67
Min
Default
Max
Units
PGS Second Engine Speed Limit
PS27
N/A
1800
RPM
PS30
Page 67
Min
Default
Max
Units
PGS Highest Gear
>PS30
N/A
TOP
GEAR
GEAR #

Paccar MX-13 Specifications

General

Engine Type	Diesel
Displacement	12.9 liters
Configuration	Inline 6-cylinder
Horsepower Range	405-510 hp
Torque Range	1450-1850 lb-ft
Bore	5.12 inches
Fuel System	Common Rail
Emissions	GHG17 compliant
Oil Capacity	42 quarts
Coolant Capacity	56 liters
Aftertreatment	Diesel Particulate Filter (DPF), Selective Catalytic Reduction (SCR)
Stroke	6.42 inches (163 mm)
