Paccar MX-13 - Interlocks; Global Limits and Set Points

PEC017
5/3/2018 Page 60 of 105
Programmable Parameters
Interlocks
N078
Page 54
Min
Default
Max
Units
Disable PTO Mode w/Clutch
Depressed
OFF (0)
ON (1)
ON (1)
ON/OFF
N079
Page 54
Min
Default
Max
Units
Require Parking Brake for PTO
Mode
OFF (0)
OFF (0)
ON (1)
ON/OFF
N080
Page 54
Min
Default
Max
Units
PTO Mode Vehicle Speed Limit
1
1
N001 - 6
MPH
* Must be at least 6 MPH less than Minimum Speed to Disable Cruise Control
(N001)
N089
Page 54
Min
Default
Max
Units
Neutral Required for PTO Mode
OFF (0)
ON (1)
ON (1)
ON/OFF
* With UltraShift transmissions, N089 = 0
N101
Page 54
Min
Default
Max
Units
Disable PTO Mode w/ Brake
Depressed
OFF (0)
ON (1)
ON (1)
ON/OFF
* Required for Mobile Cab Station w/ Accelerator and Switches configurations
* Required if PTO Mode Vehicle Speed Limit (N080) is greater than 3 MPH
Global Limits and Set Points
N076
Page 55
Min
Default
Max
Units
Maximum Engine Speed using
Pedal Input
N106
2000
2000
RPM
* Must be greater than or equal to PTO Mode Minimum Engine Speed (N106)
N077
Page 56
Min
Default
Max
Units
Maximum Engine Torque in PTO
Mode
148
1902
1902
LB-FT
